Application Programming Interface: Python v2.2

Build a deeper understanding of the MachineMotion Python API by consulting this developers reference manual. The MachineMotion python API can be used to quickly build custom applications to control your Vention fixture.

This manual refers to version 2.2 of the API, which is compatible with controller software version 1.2.11 and later. To get your controller software version, refer to the user Manual here.

If this is your first time using the machine motion controller, please follow the Python programming manual here.

configAxis ( axis, uStep, mechGain )

Description
Configures motion parameters for a single axis.

Parameters

axis ( Required ) Number - The axis to configure.
uStep ( Required ) Number - The microstep setting of the axis.
mechGain ( Required ) Number - The distance moved by the actuator for every full rotation of the stepper motor, in mm/revolution.

Return Value

None
    def configAxis(self, axis, uStep, mechGain):
        self._restrictInputValue("axis", axis,  AXIS_NUMBER)
        self._restrictInputValue("uStep", uStep, MICRO_STEPS)

        uStep    = float(uStep)
        mechGain = float(mechGain)

        if(axis == 1):
            self.myAxis1_steps_mm = 200 * uStep / mechGain
            self.myGCode.__emit__("M92 " + self.myGCode.__getTrueAxis__(axis) + str(self.myAxis1_steps_mm))
        elif(axis == 2):
            self.myAxis2_steps_mm = 200 * uStep / mechGain
            self.myGCode.__emit__("M92 " + self.myGCode.__getTrueAxis__(axis) + str(self.myAxis2_steps_mm))
        elif(axis == 3):
            self.myAxis3_steps_mm = 200 * uStep / mechGain
            self.myGCode.__emit__("M92 " + self.myGCode.__getTrueAxis__(axis) + str(self.myAxis3_steps_mm))
import sys
sys.path.append("..")
from _MachineMotion import *

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows)

# Configure the axis number 1, 8 uSteps and 150 mm / turn for a timing belt
axis = AXIS_NUMBER.DRIVE1
uStep = MICRO_STEPS.ustep_8
mechGain = MECH_GAIN.timing_belt_150mm_turn
mm.configAxis(axis, uStep, mechGain)
print("Axis " + str(axis) + " configured with " + str(uStep) + " microstepping and " + str(mechGain) + "mm/turn mechanical gain")
NOTE:
The uStep setting is hardcoded into the machinemotion controller through a DIP switch and is by default set to 8. The value here must match the value on the DIP Switch.

configAxisDirection ( axis, direction )

Description
Configures a single axis to operate in either clockwise (normal) or counterclockwise (reverse) mode. Refer to the Automation System Diagram for the correct axis setting.

Parameters

axis ( Required ) Number - The specified axis.
direction ( Required ) String - A string of value either either 'Normal' or 'Reverse'. 'Normal' direction means the axis will home towards end stop sensor A and reverse will make the axis home towards end stop B.

Return Value

None
    def configAxisDirection(self, axis, direction):

        self._restrictInputValue("axis", axis, AXIS_NUMBER)
        self._restrictInputValue("direction", direction, AXIS_DIRECTION)

        if(axis == 1):
            self.myAxis1_direction = direction
            if(direction == AXIS_DIRECTION.normal):
                self.myGCode.__emit__("M92 " + self.myGCode.__getTrueAxis__(axis) + str(self.myAxis1_steps_mm))
            elif (direction == AXIS_DIRECTION.reverse):
                self.myGCode.__emit__("M92 " + self.myGCode.__getTrueAxis__(axis) + "-" + str(self.myAxis1_steps_mm))
        elif(axis == 2):
            if(direction == AXIS_DIRECTION.normal):
                self.myGCode.__emit__("M92 " + self.myGCode.__getTrueAxis__(axis) + str(self.myAxis2_steps_mm))
            elif (direction == AXIS_DIRECTION.reverse):
                self.myGCode.__emit__("M92 " + self.myGCode.__getTrueAxis__(axis) + "-" + str(self.myAxis2_steps_mm))
        elif(axis == 3):
            if(direction == AXIS_DIRECTION.normal):
                self.myGCode.__emit__("M92 " + self.myGCode.__getTrueAxis__(axis) + str(self.myAxis3_steps_mm))
            elif (direction == AXIS_DIRECTION.reverse):
                self.myGCode.__emit__("M92 " + self.myGCode.__getTrueAxis__(axis) + "-" + str(self.myAxis3_steps_mm))
import sys
sys.path.append("..")
from _MachineMotion import *

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows)

axis = AXIS_NUMBER.DRIVE1
mm.configAxis(axis, MICRO_STEPS.ustep_8, MECH_GAIN.timing_belt_150mm_turn)

homesTowards={
    AXIS_DIRECTION.positive: "sensor " + str(axis) + "A",
    AXIS_DIRECTION.negative: "sensor " + str(axis) + "B"
}

direction = AXIS_DIRECTION.positive
print("Axis " + str(axis) + " is set to " + direction + " mode. It will now home towards " + homesTowards[direction] + "." )
mm.configAxisDirection(axis, direction)
mm.emitHome(axis)

mm.waitForMotionCompletion()

direction = AXIS_DIRECTION.negative
print("Axis " + str(axis) + " is set to " + direction + " mode. It will now home towards " + homesTowards[direction] + "." )
mm.configAxisDirection(axis, direction)
mm.emitHome(axis)

mm.waitForMotionCompletion()
NOTE:
For more details on how to properly set the axis direction, please see here

configHomingSpeed ( axes, speeds, units )

Description
Sets homing speed for all 3 axes.

Parameters

axes ( Required ) List - A list of the axes to configure. ex - [1,2,3]
speeds ( Required ) List - A list of homing speeds to set for each axis. ex - [50, 50, 100]
units ( Optional. Default = UNITS_SPEED.mm_per_sec ) String - Units for speed. Can be switched to UNITS_SPEED.mm_per_min

Return Value

None
    def configHomingSpeed(self, axes, speeds, units = UNITS_SPEED.mm_per_sec):
        try:
            axes = list(axes)
            speeds = list(speeds)
        except TypeError:
            axes = [axes]
            speeds = [speeds]

        if len(axes) != len(speeds):
            class InputsError(Exception):
                pass
            raise InputsError("axes and speeds must be of same length")

        gCodeCommand = "V2 "
        for idx, axis in enumerate(axes):

            if units == UNITS_SPEED.mm_per_sec:
                speed_mm_per_min = speeds[idx] * 60
            elif units == UNITS_SPEED.mm_per_min:
                speed_mm_per_min = speeds[idx]



            if speed_mm_per_min < HARDWARE_MIN_HOMING_FEEDRATE:
                raise self.HomingSpeedOutOfBounds("Your desired homing speed of " + str(speed_mm_per_min) + "mm/min can not be less than " + str(HARDWARE_MIN_HOMING_FEEDRATE) + "mm/min (" + str(HARDWARE_MIN_HOMING_FEEDRATE/60) + "mm/sec).")
            if speed_mm_per_min > HARDWARE_MAX_HOMING_FEEDRATE:
                raise self.HomingSpeedOutOfBounds("Your desired homing speed of " + str(speed_mm_per_min) + "mm/min can not be greater than " + str(HARDWARE_MAX_HOMING_FEEDRATE) + "mm/min (" + str(HARDWARE_MAX_HOMING_FEEDRATE/60) + "mm/sec)")

            gCodeCommand = gCodeCommand + self.myGCode.__getTrueAxis__(axis) + str(speed_mm_per_min) + " "

        while self.isReady() == False: pass
        gCodeCommand = gCodeCommand.strip()
        self.emitgCode(gCodeCommand)
import sys
sys.path.append("..")
from _MachineMotion import *

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows)

axes = [1,2,3]
axis =3                                    #The axis that you'd like to move
homingSpeeds = [50,50,50]                        #The homing speeds to set for each axis

mm.emitSpeed(100)
mm.emitAcceleration(50)
mm.configAxis(axis, MICRO_STEPS.ustep_8, MECH_GAIN.timing_belt_150mm_turn)

print("Moving to position = 100")
mm.emitAbsoluteMove(axis, 100)
mm.waitForMotionCompletion()

#Sets minimum and maximum allowable homing speeds for each axis
minHomingSpeeds = [20, 20, 20]
maxHomingSpeeds = [400, 400, 400]
mm.configMinMaxHomingSpeed(axes,minHomingSpeeds, maxHomingSpeeds, UNITS_SPEED.mm_per_sec)

#Sets homing speeds for all three axes. The selected homing speed must be within the range set by configMinMaxHomingSpeeds
mm.configHomingSpeed(axes, homingSpeeds)
mm.waitForMotionCompletion()

#Homes the axis at the newly configured homing speed.
mm.emitHome(axis)
mm.waitForMotionCompletion()
NOTE:
Once set, the homing speed will apply to all programs, including MachineLogic applications.

configMachineMotionIp ( mode, machineIp, machineNetmask, machineGateway )

Description
Set up the required network information for the Machine Motion controller. The router can be configured in either DHCP mode or static mode.

Parameters

mode ( Required ) Constant - Sets Network Mode to either DHCP or static addressing. Either NETWORK_MODE.static or NETWORK_MODE.dhcp
machineIp ( Required ) String - The static IP Address given to the controller. (Required if mode = NETWORK_MODE.static)
machineNetmask ( Required ) String - The netmask IP Address given to the controller. (Required if mode = NETWORK_MODE.static)
machineGateway ( Required ) String - The gateway IP Address given to the controller. (Required if mode = NETWORK_MODE.static)

Return Value

None
    def configMachineMotionIp(self, mode, machineIp="", machineNetmask="", machineGateway=""):

        if(mode == NETWORK_MODE.static):
            if '' in [machineIp, machineNetmask, machineGateway]:
               print("NETWORK ERROR: machineIp, machineNetmask and machineGateway cannot be left blank in static mode")
               quit()

        # Create a new object and augment it with the key value.
        self.myConfiguration["mode"] = mode
        self.myConfiguration["machineIp"] = machineIp
        self.myConfiguration["machineNetmask"] = machineNetmask
        self.myConfiguration["machineGateway"] = machineGateway

        self.mySocket.emit('configIp', json.dumps(self.myConfiguration))
        time.sleep(1)
import sys
sys.path.append("..")
from _MachineMotion import *

#Initialize MachineMotion with default IP address
mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows)
print("Application Message: MachineMotion Controller Connected")

#Configure machine motion with a static IP address
mode = NETWORK_MODE.static
machineIp = "192.168.0.2"
machineNetmask="255.255.255.0"
machineGateway = "192.168.0.1"
mm.configMachineMotionIp(mode, machineIp, machineNetmask, machineGateway)
print("MachineMotion configured in static mode with an ip of " + str(machineIp) +".")


#Configure MachineMotion IP to use Dynamic Host Configuration Protocol (DHCP)
mm.configMachineMotionIp(NETWORK_MODE.dhcp)
print("MachineMotion configured in DHCP mode.")

configMinMaxHomingSpeed ( axes, minspeeds, maxspeeds )

Description
Sets the minimum and maximum homing speeds for each axis.

Parameters

axes ( Required ) List - a list of the axes that require minimum and maximum homing speeds.
minspeeds ( Required ) List - the minimum speeds for each axis.
maxspeeds ( Required ) List - the maximum speeds for each axis, in the same order as the axes parameter

Return Value

None
    def configMinMaxHomingSpeed(self, axes, minspeeds, maxspeeds, units = UNITS_SPEED.mm_per_sec):
        gCodeCommand = "V1 "
        for idx, axis in enumerate(axes):

            if units == UNITS_SPEED.mm_per_sec:
                min_speed_mm_per_min = minspeeds[idx] * 60
                max_speed_mm_per_min = maxspeeds[idx] * 60
            elif units == UNITS_SPEED.mm_per_min:
                min_speed_mm_per_min = minspeeds[idx]
                max_speed_mm_per_min = maxspeeds[idx]

            if min_speed_mm_per_min < HARDWARE_MIN_HOMING_FEEDRATE:
                raise self.HomingSpeedOutOfBounds("Your desired homing speed of " + str(min_speed_mm_per_min) + "mm/min can not be less than " + str(HARDWARE_MIN_HOMING_FEEDRATE) + "mm/min (" + str(HARDWARE_MIN_HOMING_FEEDRATE/60) + "mm/sec).")
            if max_speed_mm_per_min > HARDWARE_MAX_HOMING_FEEDRATE:
                raise self.HomingSpeedOutOfBounds("Your desired homing speed of " + str(max_speed_mm_per_min) + "mm/min can not be greater than " + str(HARDWARE_MAX_HOMING_FEEDRATE) + "mm/min (" + str(HARDWARE_MAX_HOMING_FEEDRATE/60) + "mm/sec)")

            gCodeCommand = gCodeCommand + self.myGCode.__getTrueAxis__(axis) + str(min_speed_mm_per_min) + ":" + str(max_speed_mm_per_min) + " "

        while self.isReady() == False: pass
        gCodeCommand = gCodeCommand.strip()
        self.emitgCode(gCodeCommand)
import sys
sys.path.append("..")
from _MachineMotion import *

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows)

axes = [1,2,3]
axis =3                                    #The axis that you'd like to move
homingSpeeds = [50,50,50]                        #The homing speeds to set for each axis

mm.emitSpeed(100)
mm.emitAcceleration(50)
mm.configAxis(axis, MICRO_STEPS.ustep_8, MECH_GAIN.timing_belt_150mm_turn)

print("Moving to position = 100")
mm.emitAbsoluteMove(axis, 100)
mm.waitForMotionCompletion()

#Sets minimum and maximum allowable homing speeds for each axis
minHomingSpeeds = [20, 20, 20]
maxHomingSpeeds = [400, 400, 400]
mm.configMinMaxHomingSpeed(axes,minHomingSpeeds, maxHomingSpeeds, UNITS_SPEED.mm_per_sec)

#Sets homing speeds for all three axes. The selected homing speed must be within the range set by configMinMaxHomingSpeeds
mm.configHomingSpeed(axes, homingSpeeds)
mm.waitForMotionCompletion()

#Homes the axis at the newly configured homing speed.
mm.emitHome(axis)
mm.waitForMotionCompletion()
NOTE:
This function can be used to set safe limits on homing speed. Because homing speed is configured only through software aPI, this safeguards against developers accidently modifying homing speed to unsafe levels.

detectIOModules ( )

Description
Returns a dictionary containing all detected IO Modules.

Return Value

Dictionary Dictionary with keys of format "Digital IO Network Id [id]" and values [id] where [id] is the network IDs of all connected digital IO modules.
    def detectIOModules(self):
        class NoIOModulesFound(Exception):
            pass

        foundIOModules = {}
        numIOModules = 0

        for ioDeviceID in range(0,3):
            if self.isIoExpanderAvailable(ioDeviceID):
                foundIOModules["Digital IO Network Id " + str(ioDeviceID)] = ioDeviceID
                numIOModules = numIOModules + 1

        if numIOModules == 0:
            raise NoIOModulesFound("Application Error: No IO Modules found. Please verify the connection between Digital IO and MachineMotion.")
        else:
            return foundIOModules
# System imports
import sys
# Custom imports
sys.path.append("..")

from _MachineMotion import *

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows)


#Reads and Prints all input values on all connected digital IO Modules
detectedIOModules = mm.detectIOModules()
for IO_Name, IO_NetworkID in detectedIOModules.items():
   readPins = {"Pin 1":0, "Pin 2":1, "Pin 3": 2, "Pin 4":3}
   for readPin in readPins:
       pinValue = mm.digitalRead(IO_NetworkID, readPins[readPin])
       print(readPin + " on " + IO_Name + " has value " + str(pinValue))
NOTE:
For more information, please see the digital IO datasheet here

digitalRead ( deviceNetworkId, pin )

Description
Reads the state of a digital IO modules input pins.

Parameters

deviceNetworkId ( Required ) Integer - The IO Modules device network ID. It can be found printed on the product sticker on the back of the digital IO module.
pin ( Required ) Integer - The index of the input pin.

Return Value

Integer Returns 1 if the input pin is 24V and returns 0 if the input pin is 0V.
    def digitalRead(self, deviceNetworkId, pin):

        if ( not self.isIoExpanderInputIdValid( deviceNetworkId, pin ) ):
            logging.warning("DEBUG: unexpected digital-output parameters: device= " + str(device) + " pin= " + str(pin))
            return
        if (not hasattr(self, 'digitalInputs')):
            self.digitalInputs = {}
        if (not deviceNetworkId in self.digitalInputs):
            self.digitalInputs[deviceNetworkId] = {}
        if (not pin in self.digitalInputs[deviceNetworkId]):
            self.digitalInputs[deviceNetworkId][pin] = 0
        return self.digitalInputs[deviceNetworkId][pin]
# System imports
import sys
# Custom imports
sys.path.append("..")

from _MachineMotion import *

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows)


#Reads and Prints all input values on all connected digital IO Modules
detectedIOModules = mm.detectIOModules()
for IO_Name, IO_NetworkID in detectedIOModules.items():
   readPins = {"Pin 1":0, "Pin 2":1, "Pin 3": 2, "Pin 4":3}
   for readPin in readPins:
       pinValue = mm.digitalRead(IO_NetworkID, readPins[readPin])
       print(readPin + " on " + IO_Name + " has value " + str(pinValue))
NOTE:
The pin labels on the digital IO module (pin 1, pin 2, pin 3, pin 4) correspond in software to (0, 1, 2, 3). Therefore, digitalRead(deviceNetworkId, 2) will read the value on input pin 3.

digitalWrite ( deviceNetworkId, pin, value )

Description
Sets voltage on specified pin of digital IO output pin to either 24V or 0V.

Parameters

deviceNetworkId ( Required ) Integer - The IO Modules device network ID. It can be found printed on the product sticker on the back of the digital IO module.
pin ( Required ) Integer - The output pin number to write to.
value ( Required ) Integer - Writing 1 will set digial output to 24V, writing 0 will set digital output to 0V.

Return Value

None
    def digitalWrite(self, deviceNetworkId, pin, value):
        if (self.isIoExpanderOutputIdValid( deviceNetworkId, pin ) == False):
            print ( "DEBUG: unexpected digitalOutput parameters: device= " + str(deviceNetworkId) + " pin= " + str(pin) )
            return
        self.myMqttClient.publish('devices/io-expander/' + str(deviceNetworkId) + '/digital-output/' +  str(pin), '1' if value else '0')
import sys
sys.path.append("..")
from _MachineMotion import *

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows)

# Toggles the output pins on all connected IO Modules
detectedIOModules = mm.detectIOModules()
for IO_Name, IO_NetworkID in detectedIOModules.items():
    writePins ={"Pin 1":0, "Pin 2":1, "Pin 3": 2, "Pin 4":3}
    for writePin in writePins.keys():
        print(writePin + " on " + IO_Name + " is going to flash twice")

        mm.digitalWrite(IO_NetworkID, writePins[writePin], 1)
        time.sleep(1)
        mm.digitalWrite(IO_NetworkID, writePins[writePin], 0)
        time.sleep(1)
        mm.digitalWrite(IO_NetworkID, writePins[writePin], 1)
        time.sleep(1)
        mm.digitalWrite(IO_NetworkID, writePins[writePin], 0)


NOTE:
Output pins maximum sourcing current is 75 mA and the maximum sinking current is 100 mA. The pin labels on the digital IO module (pin 1, pin 2, pin 3, pin 4) correspond in software to (0, 1, 2, 3). Therefore, digitalWrite(deviceNetworkId, 2, 1) will set output pin 3 to 24V.

emitAbsoluteMove ( axis, position )

Description
Moves the specified axis to a desired end location.

Parameters

axis ( Required ) Number - The axis which will perform the absolute move command.
position ( Required ) Number - The desired end position of the axis movement.

Return Value

None
    def emitAbsoluteMove(self, axis, position):
        self._restrictInputValue("axis", axis, AXIS_NUMBER)
        global motion_completed

        motion_completed = "false"

        # Set to absolute motion mode
        self.myGCode.__emit__("G90")
        while self.isReady() != "true": pass

        # Transmit move command
        self.myGCode.__emit__("G0 " + self.myGCode.__getTrueAxis__(axis) + str(position))
        while self.isReady() != "true": pass
import sys
sys.path.append("..")
from _MachineMotion import *

# Define a callback to process controller gCode responses (if desired)
def templateCallback(data):
   print ( "Controller gCode responses " + data )

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows, gCodeCallback = templateCallback)

axis = 1                                       #The axis that you'd like to move
speed = 400                                    #The max speed you'd like to move at
acceleration = 500                             #The constant acceleration and decceleration value for the move
position = 100                                 #The absolute position you'd like to move to
mechGain = MECH_GAIN.timing_belt_150mm_turn    #The mechanical gain of the actuator on the axis
mm.configAxis(axis, MICRO_STEPS.ustep_8, mechGain)

# Home Axis before absolute move
mm.emitHome(axis)
print("Axis " + str(axis) + " is going home.")
mm.waitForMotionCompletion()
print("Axis " + str(axis) + " homed.")

# Configure movement speed, acceleration and then move
mm.emitSpeed(speed)
mm.emitAcceleration(acceleration)
mm.emitAbsoluteMove(axis, position)
print("Axis " + str(axis) + " is moving towards position " + str(position) + "mm")
mm.waitForMotionCompletion()
print("Axis " + str(axis) + " is at position " + str(position) + "mm")

emitAcceleration ( mm_per_sec_sqr, units )

Description
Sets the global acceleration for all movement commands on all axes.

Parameters

mm_per_sec_sqr ( Required ) Number - The global acceleration in mm/s^2.
units ( Optional. Default = UNITS_ACCEL.mm_per_sec_sqr ) String - Units for speed. Can be switched to UNITS_ACCEL.mm_per_min_sqr

Return Value

None
    def emitAcceleration(self, acceleration, units=UNITS_ACCEL.mm_per_sec_sqr):

        self._restrictInputValue("units", units, UNITS_ACCEL)

        if units == UNITS_ACCEL.mm_per_sec_sqr:
            accel_mm_per_sec_sqr = acceleration
        elif units == UNITS_ACCEL.mm_per_min_sqr:
            accel_mm_per_sec_sqr = acceleration/3600

        self.myGCode.__emit__("M204 T" + str(accel_mm_per_sec_sqr))
        while self.isReady() != "true": pass
import sys
sys.path.append("..")
from _MachineMotion import *

# Define a callback to process controller gCode responses (if desired)
def templateCallback(data):
   print ( "Controller gCode responses " + data )

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows, gCodeCallback = templateCallback)

acceleration = 500      # The acceleration [mm/s^2] that all subsequent moves will move at
mm.emitAcceleration(acceleration)
print("Global acceleration set to " + str(acceleration))

emitCombinedAxesAbsoluteMove ( axes, positions )

Description
Moves multiple specified axes to their desired end locations synchronously.

Parameters

axes ( Required ) List - The axes which will perform the move commands. Ex - [1 ,3]
positions ( Required ) List - The desired end position of all axess movement. Ex - [50, 10]

Return Value

None
    def emitCombinedAxesAbsoluteMove(self, axes, positions):

        try:
            axes = list(axes)
            positions = list(positions)
        except TypeError:
            raise TypeError("Axes and Postions must be either lists or convertible to lists")

        for axis in axes:
            self._restrictInputValue("axis", axis, AXIS_NUMBER)

        global motion_completed

        motion_completed = "false"

        # Set to absolute motion mode
        self.myGCode.__emit__("G90")
        while self.isReady() != "true": pass

        # Transmit move command
        command = "G0 "
        for axis, position in zip(axes, positions):
            command += self.myGCode.__getTrueAxis__(axis) + str(position) + " "
        self.myGCode.__emit__(command)
        while self.isReady() != "true": pass
import sys
sys.path.append("..")
from _MachineMotion import *


#Declare parameters for combined absolute move
speed = 500
acceleration = 500
axesToMove = [1,2,3]
positions = [50, 100,50]
mechGain = MECH_GAIN.timing_belt_150mm_turn

# Define a callback to process controller gCode responses (if desired)
def templateCallback(data):
   print ( "Controller gCode responses " + data )

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows, gCodeCallback = templateCallback)

mm.emitSpeed(speed)
mm.emitAcceleration(acceleration)
for axis in axesToMove:
    mm.configAxis(axis, MICRO_STEPS.ustep_8, mechGain)
print("All Axes Moving Home Sequentially")
mm.emitHomeAll()
mm.waitForMotionCompletion()
print("All Axes homed.")

# Simultaneously moves three axis:
#   Moves axis 1 to absolute position 50
#   Moves axis 2 to absolute position 100
#   Moves axis 3 to absolute position 50
mm.emitCombinedAxesAbsoluteMove(axesToMove, positions)
mm.waitForMotionCompletion()
for index, axis in enumerate(axesToMove):
    print("Axis " + str(axis) + " moved to position " + str(positions[index]))
NOTE:
The current speed and acceleration settings are applied to the combined motion of the axes.

emitCombinedAxisRelativeMove ( axes, directions, distances )

Description
Moves the multiple specified axes the specified distances in the specified directions.

Parameters

axes ( Required ) List of Integers - The axes to move. Ex-[1,3]
directions ( Required ) List of Strings - The direction of travel of each specified axis. Ex - ["positive", "negative"]
distances ( Required ) List of Numbers - The travel distances in mm. Ex - [10, 40]

Return Value

None
    def emitCombinedAxisRelativeMove(self, axes, directions, distances):

        try:
            axes = list(axes)
            directions = list(directions)
            distances = list(distances)
        except TypeError:
            raise TypeError("Axes, positions and distances must be either lists or convertible to lists")

        for axis in axes:
            self._restrictInputValue("axis", axis, AXIS_NUMBER)
        for direction in directions:
            self._restrictInputValue("direction", direction, AXIS_DIRECTION)

        global motion_completed

        motion_completed = "false"

        # Temporarily set to relative motion mode
        self.myGCode.__emit__("G91")
        while self.isReady() != "true": pass


        # Transmit move command
        command = "G0 "
        for axis, direction, distance in zip(axes, directions, distances):
            if direction == AXIS_DIRECTION.positive: distance = "" + str(distance)
            elif direction  == AXIS_DIRECTION.negative: distance = "-" + str(distance)
            command += self.myGCode.__getTrueAxis__(axis) + str(distance) + " "
        self.myGCode.__emit__(command)
        while self.isReady() != "true": pass
        return
import sys
sys.path.append("..")
from _MachineMotion import *

#declare parameters for combine move
speed = 500
acceleration = 500
axesToMove = [1,2]
distances = [50, 100, 50]
directions = ["positive","positive","positive"]
mechGain = MECH_GAIN.timing_belt_150mm_turn

# Define a callback to process controller gCode responses (if desired)
def templateCallback(data):
   print ( "Controller gCode responses " + data )

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows, gCodeCallback = templateCallback)

mm.emitSpeed(speed)
mm.emitAcceleration(acceleration)
for axis in axesToMove:
    mm.configAxis(axis, MICRO_STEPS.ustep_8, mechGain)
mm.emitHomeAll()
mm.waitForMotionCompletion()
print("All Axes homed.")

# Simultaneously moves three axis:
#   Move axis 1 in the positive direction by 50 mm
#   Move axis 2 in the negative direction by 100 mm
#   Move axis 3 in the positive direction by 50 mm
mm.emitCombinedAxisRelativeMove(axesToMove, directions, distances)


mm.waitForMotionCompletion()
for index, axis in enumerate(axesToMove):
    print("Axis " + str(axis) + " moved " + str(distances[index]) + " in the " + directions[index] + " direction.")
NOTE:
The current speed and acceleration settings are applied to the combined motion of the axes.

emitDwell ( miliseconds )

Description
Pauses motion for a specified time. This function is non-blocking; your program may accomplish other tasks while the machine is dwelling.

Parameters

miliseconds ( Required ) Integer - The duration to wait in milliseconds.

Return Value

None
    def emitDwell(self, milliseconds):
        self.myGCode.__emit__("G4 P"+str(milliseconds))
        while self.isReady() != "true": pass
import sys
sys.path.append("..")
from _MachineMotion import *

#Declare parameters for g-Code command
speed = 1000
acceleration = 2000
mechGain = MECH_GAIN.timing_belt_150mm_turn

# Define a callback to process controller gCode responses (if desired)
def templateCallback(data):
   print ( "Controller gCode responses " + data )

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows, gCodeCallback = templateCallback)

axis = AXIS_NUMBER.DRIVE1

mm.configAxis(axis, MICRO_STEPS.ustep_8, MECH_GAIN.timing_belt_150mm_turn)

mm.emitSpeed(speed)
mm.emitAcceleration(acceleration)
mm.emitHome(axis)
mm.configAxis(AXIS_NUMBER.DRIVE1, MICRO_STEPS.ustep_8, mechGain)
# Moves axis back and forth, waiting a specified amount of time between each move
mm.emitAbsoluteMove(axis, 100)
mm.emitDwell(250)
mm.emitAbsoluteMove(axis, 50)
mm.emitDwell(500)
mm.emitAbsoluteMove(axis, 100)
mm.emitDwell(1000)
mm.emitAbsoluteMove(axis, 50)
mm.emitDwell(5000)
print("emitDwell does not block this line from printing")
mm.waitForMotionCompletion()
print("but waitForMotionCompletion() will force python to wait the full 5000ms until emitDwell has finished.")
NOTE:
The timer starts after all previous MachineMotion movement commands have finished execution.

emitHome ( axis )

Description
Initiates the homing sequence for the specified axis.

Parameters

axis ( Required ) Number - The axis to be homed.

Return Value

None
    def emitHome(self, axis):
        self._restrictInputValue("axis", axis, AXIS_NUMBER)

        global motion_completed

        motion_completed = "false"

        self.myGCode.__emit__("G28 " + self.myGCode.__getTrueAxis__(axis))
import sys
sys.path.append("..")
from _MachineMotion import *

# Define a callback to process controller gCode responses (if desired)
def templateCallback(data):
   print ( "Controller gCode responses " + data )

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows, gCodeCallback = templateCallback)

axis = AXIS_NUMBER.DRIVE1

mm.configAxis(axis, MICRO_STEPS.ustep_8, MECH_GAIN.timing_belt_150mm_turn)
mm.emitHome(axis)
print ("Application Message: Axis "+ str(axis) +" is going home")
mm.waitForMotionCompletion()
print("Application Message: Axis "+ str(axis) +" is at home")
NOTE:
If configAxisDirection is set to "normal" on axis 1, axis 1 will home itself towards sensor 1A. If configAxisDirection is set to "reverse" on axis 1, axis 1 will home itself towards sensor 1B.

emitHomeAll ( )

Description
Initiates the homing sequence of all axes. All axes will home sequentially (Axis 1, then Axis 2, then Axis 3).

Return Value

None
    def emitHomeAll(self):

        global motion_completed

        motion_completed = "false"

        self.myGCode.__emit__("G28")
import sys
sys.path.append("..")
from _MachineMotion import *

# Define a callback to process controller gCode responses (if desired)
def templateCallback(data):
   print ( "Controller gCode responses " + data )

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows, gCodeCallback = templateCallback)

# Home All Axes Sequentially
mm.emitHomeAll()
print ("All Axes Moving Home")
mm.waitForMotionCompletion()
print("All Axes Homed")

emitRelativeMove ( axis, direction, distance )

Description
Moves the specified axis the specified distance in the specified direction.

Parameters

axis ( Required ) Integer - The axis to move.
direction ( Required ) String - The direction of travel. Ex - "positive" or "negative"
distance ( Required ) Number - The travel distance in mm.

Return Value

None
    def emitRelativeMove(self, axis, direction, distance):

        self._restrictInputValue("axis",axis, AXIS_NUMBER)
        self._restrictInputValue("direction", direction, AXIS_DIRECTION)

        global motion_completed

        motion_completed = "false"


        self.myGCode.__emit__("G91")
        while self.isReady() != "true": pass

        if direction == "positive":distance = "" + str(distance)
        elif direction  == "negative": distance = "-" + str(distance)

        # Transmit move command
        self.myGCode.__emit__("G0 " + self.myGCode.__getTrueAxis__(axis) + str(distance))
        while self.isReady() != "true": pass

        return
import sys
sys.path.append("..")
from _MachineMotion import *

# Define a callback to process controller gCode responses (if desired)
def templateCallback(data):
   print ( "Controller gCode responses " + data )

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows, gCodeCallback = templateCallback)

#Define Relative Move Parameters
axis = 1
speed = 400
acceleration = 500
distance = 100
direction = "positive"
mechGain = MECH_GAIN.rack_pinion_mm_turn

#Load Relative Move Parameters
mm.emitSpeed(speed)
mm.emitAcceleration(acceleration)
mm.configAxis(axis, MICRO_STEPS.ustep_8, mechGain)

#Home Axis Before Move
print("Axis " + str(axis) + " moving home.")
mm.emitHome(axis)
mm.waitForMotionCompletion()
print("Axis " + str(axis) + " homed")

#Begin Relative Move
mm.emitRelativeMove(axis, direction, distance)
mm.waitForMotionCompletion()
print("Axis " + str(axis) + " moved " + str(distance) + "mm in the " + direction + " direction")

emitSpeed ( speed, units )

Description
Sets the global speed for all movement commands on all axes.

Parameters

speed ( Required ) Number - The global max speed in mm/min.
units ( Optional. Default = UNITS_SPEED.mm_per_sec ) String - Units for speed. Can be switched to UNITS_SPEED.mm_per_min

Return Value

None
    def emitSpeed(self, speed, units = UNITS_SPEED.mm_per_sec):

        self._restrictInputValue("units", units, UNITS_SPEED)

        if units == UNITS_SPEED.mm_per_min:
            speed_mm_per_min = speed
        elif units == UNITS_SPEED.mm_per_sec:
            speed_mm_per_min = 60*speed


        self.myGCode.__emit__("G0 F" + str(speed_mm_per_min))
        while self.isReady() != "true": pass
import sys
sys.path.append("..")
from _MachineMotion import *

# Define a callback to process controller gCode responses (if desired)
def templateCallback(data):
   print ( "Controller gCode responses " + data )

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows, gCodeCallback = templateCallback)

speed = 500      # The speed [mm/s] that all subsequent moves will move at
mm.emitSpeed(speed)
print("Global acceleration set to " + str(speed))

emitStop ( )

Description
Immediately stops all motion of all axes.

Return Value

None
    def emitStop(self):
        global motion_completed

        motion_completed = "false"

        self.myGCode.__emit__("M410")

        # Wait and send a dummy packet to insure that other commands after the emit stop are not flushed.
        time.sleep(0.500)
        self.myGCode.__emit__("G91")
        while self.isReady() != "true": pass
        self.myGCode.__emit__("G0 X0")
        while self.isReady() != "true": pass
import sys
sys.path.append("..")
from _MachineMotion import *

import time

# Define a callback to process controller gCode responses (if desired)
def templateCallback(data):
   print ( "Controller gCode responses " + data )

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows, gCodeCallback = templateCallback)

#Define Relative Move Parameters
axis = 1
speed = 400
acceleration = 500
distance = 1000
direction = "positive"
mechGain = MECH_GAIN.rack_pinion_mm_turn

#Load Relative Move Parameters
mm.emitSpeed(speed)
mm.emitAcceleration(acceleration)
mm.configAxis(axis, MICRO_STEPS.ustep_8, mechGain)

#Home Axis Before Move
mm.emitHome(axis)
print("Axis " + str(axis) + " is going home")
mm.waitForMotionCompletion()
print("Axis " + str(axis) + " homed")

#Begin Relative Move
mm.emitRelativeMove(axis, direction, distance)
print("Axis " + str(axis) + " is moving " + str(distance) + "mm in the " + direction + " direction")

#This move should take 5 (distance/speed) seconds to complete. Instead, we wait 2 seconds and then stop the machine.
time.sleep(2)
mm.emitStop()
print("Axis " + str(axis) + " stopped.")
NOTE:
This function is a hard stop. It is not a controlled stop and consequently does not decelerate smoothly to a stop. Additionally, this function is not intended to serve as an emergency stop since this stop mechanism does not have safety ratings.

emitgCode ( gCode )

Description
Executes raw gCode on the controller.

Parameters

gCode ( Required ) string - The g-code that will be passed directly to the controller.

Return Value

None
    def emitgCode(self, gCode):
        global motion_completed

        motion_completed = "false"

        self.myGCode.__emit__(gCode)
import sys
sys.path.append("..")
from _MachineMotion import *

#Declare parameters for g-Code command
speed = 500
acceleration = 500
mechGain = MECH_GAIN.timing_belt_150mm_turn

# Define a callback to process controller gCode responses (if desired)
def templateCallback(data):
   print ( "Controller gCode responses " + data )

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows, gCodeCallback = templateCallback)

mm.emitSpeed(speed)
mm.emitAcceleration(acceleration)
mm.emitHomeAll()
print("All Axes homed.")

# Use the G0 command to move both axis 1 and 2 by 50mm
gCodeCommand = "G0 X50 Y50"
mm.emitgCode(gCodeCommand)
mm.waitForMotionCompletion()
print("G-code command '" + gCodeCommand + "' completed by MachineMotion.")
NOTE:
All movement commands sent to the controller are by default in mm.

getCurrentPositions ( )

Description
Returns the current position of each axis.

Return Value

Dictionary A dictionary containing the current position of each axis.
    def getCurrentPositions(self):
        global waiting_current_position

        waiting_current_position = "true"
        self.myGCode.__emit__("M114")
        while self.isReady() != "true" and waiting_current_position == "true": pass

        return self.myGCode.currentPositions
NOTE:
This function returns the 'open loop' position of each axis. If your axis has an encoder, please use readEncoder.

getData ( key )

Description
Retreives saved/persisted data from the MachineMotion controller (in key-data pairs). If the controller takes more than 3 seconds to return data, the function will return with a value of "Error - getData took too long" under the given key.

Parameters

key ( Required ) String - A Unique identifier representing the data to be retreived

Return Value

Dictionary A dictionary containing the saved data.
    def getData(self, key):

        getDataAvailable = threading.Event()
        dataTimedOut = threading.Event()

        def asyncGetData(key, callback):
            #Send the request to MachineMotion
            self.mySocket.emit('getData', key)
            # On reception of the data invoke the callback function.
            self.mySocket.on('getDataResponse', callback)

        def asyncCallback(data):
            self.asyncResult = data
            getDataAvailable.set()

        def threadTimeout():
           time.sleep(3)
           dataTimedOut.set()

        #timer here to force call asyncCallback on timeout #kill timer#
        # If this fails, return a key value pair - key is 'error' value is description why error failed
        getDataThread = threading.Thread(target = asyncGetData, args=(key, asyncCallback,))
        timeoutThread = threading.Thread(target = threadTimeout)

        getDataThread.start()
        timeoutThread.start()
        while True:
            if getDataAvailable.isSet():
                getDataResult = json.loads("".join(self.asyncResult))
                return getDataResult
            elif dataTimedOut.isSet():
                getDataResult = json.loads('{"data":"Error - getData took too long"}')
                return getDataResult
import sys
sys.path.append("..")
from _MachineMotion import *

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows)

# Initialize the key-value pair to save on the controller
dataKey = "example_key"
dataContent = "save_this_string_on_the_controller"

# Saving a string on the controller
mm.saveData(dataKey, dataContent)
print("Data: '" + dataContent + "' saved on controller under key '" + dataKey + "'")

# Retreiving data from the controller
retrievedData = mm.getData(dataKey)
print("Data: '" + retrievedData['data'] + "' retrieved from controller using key '" + dataKey + "'")

readEncoder ( encoder, readingType )

Description
Returns the last received encoder position in counts.

Parameters

encoder ( Required ) Integer - The identifier of the encoder to read
readingType ( Required ) String - Either 'real time' or 'stable'. In 'real time' mode, readEncoder will return the most recently received encoder information. In 'stable' mode, readEncoder will update its return value only after the encoder output has stabilized around a specific value, such as when the axis has stopped motion.

Return Value

Integer The current position of the encoder, in counts. The encoder has 3600 counts per revolution.
    def readEncoder(self, encoder, readingType="realTime"):
        self._restrictInputValue("readingType", readingType, ENCODER_TYPE)

        if (self.isEncoderIdValid( encoder ) == False):
            print ( "DEBUG: unexpected encoder identifier: encoderId= " + str(encoder) )
            return

        if readingType == ENCODER_TYPE.real_time:
            self.myEncoderStablePositions
            return self.myEncoderRealtimePositions[encoder]
        elif readingType == ENCODER_TYPE.stable:
            return self.myEncoderStablePositions[encoder]

        return
import sys
sys.path.append("..")
from _MachineMotion import *

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows)

#Adjust this line to match whichever AUX port the encoder is plugged into
encoderPort = AUX_PORTS.aux_1
encoderPortLabel = {AUX_PORTS.aux_1: "AUX 1", AUX_PORTS.aux_2: "AUX 2", AUX_PORTS.aux_3: "AUX 3"}

checkInput = True
print("Reading and printing encoder output for 10 seconds:")
for i in range(1,30):
   realTimeOutput = mm.readEncoder(encoderPort, ENCODER_TYPE.real_time)
   stableOutput = mm.readEncoder(encoderPort, ENCODER_TYPE.stable)
   print("Encoder on port " + encoderPortLabel[encoderPort] + "\t Realtime Position =" + str(realTimeOutput) + " counts\t StablePosition = " + str(stableOutput))
   time.sleep(.25)

   if realTimeOutput != 0:
      checkInput = False

if(checkInput):
   print("The encoder is not receiving any data. Please check the following: \n\t Is the encoder plugged into " + str(encoderPortLabel[encoderPort]) + "? \n\t Ensure the encoder rotates during program execution. (Readings are triggered only when the encoder moves)")
NOTE:
The encoder position returned by this function may be delayed by up to 250 ms due to internal propogation delays.

saveData ( key, data )

Description
Saves/persists data within the MachineMotion Controller in key - data pairs.

Parameters

key ( Required ) String - A string that uniquely identifies the data to save for future retreival.
data ( Required ) String - The data to save to the machine. The data must be convertible to JSON format.

Return Value

None
    def saveData(self, key, data):

        # Create a new object and augment it with the key value.
        dataPack = {}
        dataPack["fileName"] = key
        dataPack["data"] = data

        # Send the request to MachineMotion
        self.mySocket.emit('saveData', json.dumps(dataPack))
        time.sleep(0.05)
import sys
sys.path.append("..")
from _MachineMotion import *

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows)

# Initialize the key-value pair to save on the controller
dataKey = "example_key"
dataContent = "save_this_string_on_the_controller"

# Saving a string on the controller
mm.saveData(dataKey, dataContent)
print("Data: '" + dataContent + "' saved on controller under key '" + dataKey + "'")

# Retreiving data from the controller
retrievedData = mm.getData(dataKey)
print("Data: '" + retrievedData['data'] + "' retrieved from controller using key '" + dataKey + "'")
NOTE:
The Data continues to exist even when the controller is shut off. However, writing to a previously used key will override the previous value.

setPosition ( axis, position )

Description
Override the current position of the specified axis to a new value.

Parameters

axis ( Required ) Number - Overrides the position on this axis.
position ( Required ) Number - The new position value in mm.

Return Value

None
    def setPosition(self, axis, position):
        self._restrictInputValue("axis", axis, AXIS_NUMBER)

        # Transmit move command
        self.myGCode.__emit__("G92 " + self.myGCode.__getTrueAxis__(axis) + str(position))
        while self.isReady() != "true": pass
import sys
sys.path.append("..")
from _MachineMotion import *

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows)

axis = 1                                    #The axis that you'd like to move
speed = 400                                 #The max speed you'd like to move at
acceleration = 500                          #The constant acceleration and decceleration value for the move
position = 100                              #The absolute position you'd like to move to
mechGain = MECH_GAIN.rack_pinion_mm_turn    #The mechanical gain of the actuator on the axis

mm.emitSpeed(speed)
mm.emitAcceleration(acceleration)
mm.configAxis(axis, MICRO_STEPS.ustep_16, mechGain)

mm.emitHome(axis)
mm.waitForMotionCompletion()
print("Axis " + str(axis) + " homed")

print("Absolute Moves are referenced from home")
mm.emitAbsoluteMove(axis, position)
mm.waitForMotionCompletion()
print("Axis " + str(axis) + " is " + str(position) + "mm away from home")

mm.setPosition(axis, 0)
print("Absolute moves on axis " + str(axis) + " are now referenced from " +  str(position) + "mm from home. ")
time.sleep(2)
position2 = 30
print("Now moving to absolute Position " + str(position2) + " mm, referenced from location 'setPosition' was called")
mm.emitAbsoluteMove(axis, position2)
mm.waitForMotionCompletion()
print("Axis " + str(axis) + " is now " + str(position2) + "mm from reference position and " + str(position + position2) + "mm from home")

waitForMotionCompletion ( )

Description
Pauses python program execution until machine has finished its current movement.

Return Value

None
    def waitForMotionCompletion(self):
        global waiting_motion_status

        waiting_motion_status = "true"
        self.emitgCode("V0")
        while  self.isMotionCompleted() != "true": pass
import sys
sys.path.append("..")
from _MachineMotion import *

# Define a callback to process controller gCode responses (if desired)
def templateCallback(data):
   print ( "Controller gCode responses " + data )

mm = MachineMotion(DEFAULT_IP_ADDRESS.usb_windows, gCodeCallback = templateCallback)

mm.emitHome(1)

# Move the axis one to position 100 mm
mm.emitAbsoluteMove(1, 100)
print("This message gets printed immediately")
mm.waitForMotionCompletion()
print("This message gets printed once machine is finished moving")

Comments (0)
