T-Slot Extrusion System for Industrial Tooling and Machine Frames

Vention's patent-pending extrusion system is designed to give you more rigidity and precision.

Four Standard Profiles, One Set of Fasteners and Assembly Plates

Extrusion image Extrusion image Extrusion image Extrusion image
Inertia (mm4)
8,232
154,188
265,366
180,661
Surface Area (mm2)
153.33
790.7
1290.2
1914.95
Weight for 100mm (kg)
0.041
0.213
0.348
0.517
Material
6063-T5
6063-T5
6063-T5
6063-T5
Fastener Size
M8
M8
M8
M8
Extrusion image
Inertia (mm4)
8,232
Surface Area (mm2)
153.33
Weight for 100mm (kg)
0.041
Material
6063-T5
Fastener Size
M8
Extrusion image
Inertia (mm4)
154,188
Surface Area (mm2)
790.7
Weight for 100mm (kg)
0.213
Material
6063-T5
Fastener Size
M8
Extrusion image
Inertia (mm4)
265,366
Surface Area (mm2)
1290.2
Weight for 100mm (kg)
0.348
Material
6063-T5
Fastener Size
M8
Extrusion image
Inertia (mm4)
180,661
Surface Area (mm2)
1914.95
Weight for 100mm (kg)
0.517
Material
6063-T5
Fastener Size
M8
Extrusion image

High Modularity

All of our extrusion profiles connect with the same set of assembly plates and fasteners.

Extrusion image

Ready to Assemble

Extrusion length available in increments of 45mm. Ready to assemble with no additional cutting or drilling required.

Extrusion image

Strong and Precise Joints

Patent-pending v-shaped groove gives more load-bearing capacity per joint. Extrusions can be used as a linear axis when combined to a gantry.

Key Benefits & Features

Feature diagram
Feature diagram
  • Computer-optimized profile with best in class moment of inertia per surface area ratio
  • Ready to assemble out of the box with no subsequent cutting or drilling required
  • Patent pending v-shape interface creates self-aligning joint, supporting up to 25% more payload than traditional assembly plates and extrusion assemblies
  • Photometry compliant blue anodized color with low reflectivity
  • Laser-engraved part numbers matching visual assembly instructions

Hundreds of Compatible Parts

Vention enables a range of applications from machine frame to automated equipment

Start Shopping

Performance Comparison

Vention's extrusions offer best-in-class rigidity and precision

Benchmark of Common Extrusion Profiles
Inertia (mm4)
Surface Area (mm2)
Inertia / Surface Area Ratio
T-Slot Nut (T-Nut) Pull Out Force (kN)
Extrusion
Vention Extrusion
154,188
790.7
195.0
166.8
Extrusion
Comparable Profile A
139,608
756.5
184.5
138.3
Extrusion
Comparable Profile B
109,946
571.4
192.4
N/A

Browse T-Slot Design Resources

Vention’s public library contains hundreds of t-slot assemblies that can be customized or ordered as is
